The ETT 305 is a practical semi-automatic twisting machine to twist multiple single wires with programmable twisting turns and directions.
1. Small size and light weight.
2. The machine is powered by a motor and only requires an electricity supply.
3. The twisting sections, twisting turns, twisting directions, and twisting speed are all programmable.
4. Custom tooling set to clamp and hold the wires.
| ETT 305 | |
|---|---|
| Conductor cross section | 0.025 - 5 mm² (total) |
| Rotation direction | Clockwise/anti-clockwise (switchable) |
| Rotational speed | 200 - 5000 RPM (adjustable) |
| Twisting length | Programmable |
| Twisting turn number | Programmable |
| Twisting tolerance | 0 |
| Twisting speed | Max. 40 turns/s |
| Max. sequence number | 20 |
| Display mode | LCD with physical button |
| Program storage capacity | 100 programs |
| Power | 90 W |
| Power supply | 220/110 V (50/60 Hz) |
| Power cord type | Different types for different standards |
| Weight | 8.2 kg |
| Dimension | 300 * 220 * 290 mm |
